A130 | A131 | A132

A130 | A131 | A132

Gaskets | O-rings | Lip Seals | Bonded Pistons | Sealing Rings

SKU #	NAME
67300B	67300B - Gasket, A130/A140 Bottom Pan 15 Bolts 1983-On
67311B	67311B - O-Ring, A130/A140/A240 Pump
67300BF	67300BF - Pan Gasket, Fiber A130L, A131L, A132L, A140E, A140L, A141E 1984-2002
67300D	67300D - Gasket, A130/A140 Bottom Pan
67300DF	67300DF - Gasket, A130/A140 Bottom Pan (Fiber)

Sonnax

SKU #	NAME
89010-01K	89010-01K - A130, A131, A140 SONNAX VALVE ASSY, BOOST
89010-02K	89010-02K - A130, A131, A140 SONNAX VALVE ASSY, BOOST

Bands

SKU #	NAME
67022B	67022B - A130 band-2nd brake-flex 1983-Up
67022A	67022A - Band, MX17 (Sprint, Suzuki) (1 1/4” Wide) 1985-Up
67050B	67050B - Bushing, A130/A140/A240 Input Hub 1983-Up

Filters | Screens

SKU #	NAME
67010B	67010B - Filter, A130/A140 (With Square Pick-Up) (2”x2 1/4”) 1983-97

Bearings | Washers

SKU #	NAME
67241A	67241A - Washer, A130/A140/A240 Rear Planet To Rear Ring Gear (Plastic) Tabs Are In The Center ID Of Washer Straight Across Center
67292B	67292B - Bearing W/Race, A130 Differential (Both Sides) (20 Rollers) 1984-89

Bushings

SKU #	NAME
67030B	67030B - Bushing Kit, A130/A140/A240 1983-Up
67037A	67037A - Bushing, A130/A140/A240 Stator (Rear) 1983-On
67046A	67046A - Bushing, A130/A140/A240 Direct Drum
67052A	67052A - Bushing, A130/A140/A240 Sun Gear 1983-Up

Metal Clad Seals

SKU #	NAME
67075A	67075A - Toyota A130, A140 Seal, A130 Pinion Shaft 1983-Up
67076A	67076A - Seal, Rear (Sidekick 4wd, Tracker 4wd) (92-Up), Axle, Right (2.145" OD) (A131L, A132L) (83-Up), Axle, Left (MX17) (83-Up)
67076B	67076B - Seal, A130/A140/A240 Axle (2.137”OD) 1983-Up
67076BA	67076BA - Seal, A130/A140/A240 Axle (2.180”OD) 1983-Up
67076BC	67076BC - Seal, A130/A140/A240 Axle (2.492”OD) 1983-Up
67077	67077 - Seal, A130 Axle left Seal, Axle, Left (A131L, A132L) (3/98-Up) & (U340E) (00-Up)

Friction Plates

SKU #	NAME
67100A	67100A - Friction, A130/A140/A240 2nd Brake/Reverse/Overdrive Brake Clutch .067” (33 Teeth) (5.60”OD)
67100B	67100B - Friction, A132L/A140 Reverse Clutch .059” (33 Teeth) (5.60”OD) 1993-Up
67106A	67106A - Friction, A130/A140/A240 Forward/Direct/Overdrive Direct Clutch .067” (40 Teeth) (4.975”OD)

Steel Plates

SKU #	NAME
67120B	67120B - Steel, A130/A140/A240 2nd Brake Clutch .071” (12 Teeth) (4.60”ID) (With 4 Notched Teeth) 1983-Up
67120C	67120C - Steel, A140 Overdrive Brake Clutch .071” (12 Teeth) (4.60”ID) 1983-86 (Also Fits A130/A140/A240 Reverse Clutch 1983-Up)
67122A	67122A - Steel, A130/A140/A240 Forward/Direct/Overdrive Direct Clutch .071” (8 Teeth) (4.160”ID)

Hard Parts

SKU #	NAME
67555CA	67555CA - Drum, A140 Direct (3 Clutch) 1 7/8”ID Bushing 2/1984-Up (Piston Is .385” Thick) Uses 1” Wide Band

Torque Converter

SKU #	NAME
TO19	TO19 - Toyota Chevy Geo MX1 MS7 A130L A131L A240E A240L A245E Transmission Torque Converter '84-'02
TO19B	TO19B - Toyota Chevy Geo MX1 MS7 A130L A131L A240E A240L A245E Transmission Torque Converter 1984-2002
TO33	TO33 - Geo Pontiac Toyota MX1 A131L A132L A241L A242L A245E A246E U341E U341F U250E Transmission Torque Converter '87-'10
TO41	TO41 - 1989 Toyota Celica GTS Transmission Torque Converter Medium Stall Lock Up
