A140 | A141 | A142

A140 | A141 | A142

Gaskets | O-rings | Lip Seals | Bonded Pistons | Sealing Rings

SKU #	NAME
67300B	67300B - Gasket, A130/A140 Bottom Pan 15 Bolts 1983-On
67300BF	67300BF - Pan Gasket, Fiber A130L, A131L, A132L, A140E, A140L, A141E 1984-2002
67300D	67300D - Gasket, A130/A140 Bottom Pan
67300DF	67300DF - Gasket, A130/A140 Bottom Pan (Fiber)

Sonnax

SKU #	NAME
89010-01K	89010-01K - A130, A131, A140 SONNAX VALVE ASSY, BOOST
89010-02K	89010-02K - A130, A131, A140 SONNAX VALVE ASSY, BOOST
89010-03K	89010-03K - A140, A540E SONNAX VALVE KIT, PR O/S

Bands

SKU #	NAME
67050B	67050B - Bushing, A130/A140/A240 Input Hub 1983-Up

Filters | Screens

SKU #	NAME
67010B	67010B - Filter, A130/A140 (With Square Pick-Up) (2”x2 1/4”) 1983-97

Bearings | Washers

SKU #	NAME
67241A	67241A - Washer, A130/A140/A240 Rear Planet To Rear Ring Gear (Plastic) Tabs Are In The Center ID Of Washer Straight Across Center

Bushings

SKU #	NAME
67030B	67030B - Bushing Kit, A130/A140/A240 1983-Up
67037A	67037A - Bushing, A130/A140/A240 Stator (Rear) 1983-On
67046A	67046A - Bushing, A130/A140/A240 Direct Drum
67052A	67052A - Bushing, A130/A140/A240 Sun Gear 1983-Up

Metal Clad Seals

SKU #	NAME
67075A	67075A - Toyota A130, A140 Seal, A130 Pinion Shaft 1983-Up
67076BA	67076BA - Seal, A130/A140/A240 Axle (2.180”OD) 1983-Up
67076BC	67076BC - Seal, A130/A140/A240 Axle (2.492”OD) 1983-Up

Friction Plates

SKU #	NAME
67100A	67100A - Friction, A130/A140/A240 2nd Brake/Reverse/Overdrive Brake Clutch .067” (33 Teeth) (5.60”OD)
67100B	67100B - Friction, A132L/A140 Reverse Clutch .059” (33 Teeth) (5.60”OD) 1993-Up
67106A	67106A - Friction, A130/A140/A240 Forward/Direct/Overdrive Direct Clutch .067” (40 Teeth) (4.975”OD)
67106C	67106C - Friction, A140/A240 Direct/Overdrive Direct Clutch .075” (40 Teeth) Smooth (4.975”OD) 1986-Up
67100CA	67100CA - Friction, A140/A240 2nd Brake Clutch .075” (33 Teeth) (5.60”OD) 1986-Up

Steel Plates

SKU #	NAME
67120B	67120B - Steel, A130/A140/A240 2nd Brake Clutch .071” (12 Teeth) (4.60”ID) (With 4 Notched Teeth) 1983-Up
67120C	67120C - Steel, A140 Overdrive Brake Clutch .071” (12 Teeth) (4.60”ID) 1983-86 (Also Fits A130/A140/A240 Reverse Clutch 1983-Up)
67120CA	67120CA - Steel, A140 Overdrive Brake Clutch .071” (12 Teeth) (5.60”ID) (With 4 Notched Teeth) 8/1986-Up
67122A	67122A - Steel, A130/A140/A240 Forward/Direct/Overdrive Direct Clutch .071” (8 Teeth) (4.160”ID)
67122C	67122C - Steel, A140 Overdrive Direct Clutch .071” (20 Teeth) (4.145”ID) 8/1986-Up
67175C	67175C - Ring Kit, A140E/A141E/A142L/A240E 1983-Up

Torque Converter

SKU #	NAME
TO33	TO33 - Geo Pontiac Toyota MX1 A131L A132L A241L A242L A245E A246E U341E U341F U250E Transmission Torque Converter '87-'10
TO41	TO41 - 1989 Toyota Celica GTS Transmission Torque Converter Medium Stall Lock Up
TO42	TO42 - Toyota A540E A541E U140E U140F A140E A140L A241E A243L A540H U241E U151E U151F U250E U241F Transmission Torque Converter '83-'09
TO51	TO51 - Toyota Camry A540E A140E Transmission Torque Converter '88-'92
